• A Doppler Echocardiographic Study of the Myocardial Inotropic Response to Peak Semisupine Exercise in Healthy Children: Development of a Simplified Index of Myocardial Reserve

  ×

  A Doppler Echocardiographic Study of the Myocardial Inotropic Response to Peak Semisupine Exercise in Healthy Children: Development of a Simplified Index of Myocardial Reserve

  Author(s)

  Anita T. Cote, PhD, D. Kathryn Duff, MPH, Carolina A. Escudero, MD, Astrid M. De Souza, MSc, Lindsey D. Williams, RDCS, Raman Gill, RDCS, M. Terri Zadorsky, RDCS, Kevin C. Harris, MD, James E. Potts, PhD, and George G. S. Sandor, MD,

  Date

  2017-08-04

  Source

  Journal of the American Society of Echocardiography

  Abstract
  BACKGROUND:
  Stress echocardiography has been advocated for the detection of abnormal myocardial function and unmasking diminished myocardial reserve in pediatric patients. The aim of this study was to create a simplified index of myocardial reserve, derived from the myocardial inotropic response to peak semisupine exercise in healthy children, and illustrate its applicability in a sample of pediatric oncology patients.

  METHODS:
  In this prospective analysis, children (7-18 years of age) with normal cardiac structure and function performed semisupine stress echocardiography to volitional fatigue. The quotient of wall stress at peak systole and heart rate-corrected velocity of circumferential fiber shortening were calculated at baseline and at peak exercise, the difference of which was termed the index of myocardial reserve (IMR). The IMR was also calculated in a retrospective sample of pediatric oncology patients with normal resting left ventricular function who had received anthracycline treatment and had performed the same exercise protocol to illustrate utility.

  RESULTS:
  Fifty healthy subjects (mean age, 13.2 ± 2.6 years) and 33 oncology patients (mean age, 12.7 ± 4.0 years) were assessed. In the healthy children at peak exercise, heart rate-corrected velocity of circumferential fiber shortening significantly increased (from 1.17 ± 0.17 to 1.58 ± 0.24 circ · sec-1, P < .001), while the quotient of wall stress at peak systole significantly decreased (from 75.3 ± 17.1 to 55.3 ± 13.8 g · cm-2, P < .001), shifting the plot of the relationship between the two parameters upward and to the left. The mean IMR was -30.8 ± 17.8, and the normal distribution ranged from -4.7 (fifth percentile) to -67.3 (95th percentile). The IMR was abnormal in 10 oncology patients who were treated with anthracyclines.

  CONCLUSIONS:
  The authors have developed a novel IMR. Relative to the normal distribution of this IMR in healthy subjects, it is possible to identify patients with abnormal myocardial reserve. Thus, this study demonstrates the application of the IMR to aid in clinical decision making in individual patients.

  Download publication

  Close
• A new ultrasonographic technique for diagnosing deep venous insufficiency–imaging and functional evaluation of venous valves by ultrasonography with improved resolution

  ×

  A new ultrasonographic technique for diagnosing deep venous insufficiency–imaging and functional evaluation of venous valves by ultrasonography with improved resolution

  Author(s)

  Kotani A, Hirano Y, Yasuda C, Ishikawa K.

  Date

  2007-08-01

  Source

  Int J Cardiovasc Imaging. 2007 Aug;23(4):493-500. Epub 2006 Nov 4.

  Abstract
  This is to demonstrate a new 2D-ultrasonographic technique which enabled clear resolution of deformed valves, visualization of venous reflux and quantitation of valve incompetence. In a 59-year-old Japanese female patient, ultrasonography was done using Aplio, Toshiba Medical Systems Co., Japan, equipped with 8 MHz linear probe capable of differential tissue harmonic imaging to diagnose the cause of her leg edema. Venous ultrasonography using this device at the popliteal venous valve in this patient demonstrated clear view of deformed venous valve and valve separation at one end of valvular agger while the other part of the valve is closed. Color Doppler failed to show venous reflux due to its low velocity. However, the appearance and disappearance of a thrombus-like echo could be imaged using 2D-ultrasonography. In addition, we were able to demonstrate the time-course change of valve opening and closing, and quantitate the valve incompetence using M-mode ultrasonography.

  Download publication

  Close
• Abnormal Coronary Flow Velocity Reserve and Decreased Myocardial Contractile Reserve Are Main Factors in Relation to Physical Exercise Capacity in Cardiac Amyloidosis

  ×

  Abnormal Coronary Flow Velocity Reserve and Decreased Myocardial Contractile Reserve Are Main Factors in Relation to Physical Exercise Capacity in Cardiac Amyloidosis

  Author(s)

  Tor Skibsted Clemmensen;Hans Eiskjær; Henning Mølgaard; Anders Hostrup Larsen; Jens Soerensen; Niels Frost Andersen; Lars Poulsen Tolbod; Hendrik J. Harms; Steen Hvitfeldt Poulsen

  Date

  2018-01-19

  Source

  Journal of the American Society of Echocardiology, January 2018Volume 31, Issue 1, Pages 71–78

  Highlights

  •Coronary flow velocity reserve is severely reduced in patients with cardiac amyloidosis.
  •Patients with cardiac amyloidosis have a profound lack of myocardial deformation capacity.
  •Coronary flow velocity reserve and myocardial deformation capacity are strongly associated with exercise capacity in patients with cardiac amyloidosis.

  Background
  The aim of the present study was to evaluate the clinical importance of echocardiographic coronary flow velocity reserve (CFVR), resting and exercise left ventricular global longitudinal strain (LVGLS), and myocardial work efficiency (MWE) in patients with cardiac amyloidosis (CA).

  Methods
  The study population comprised 69 subjects: group A, 27 patients with CA confirmed by endomyocardial biopsy (CA positive); group B, 42 healthy control subjects. The amyloid phenotype in group A was as follows: patients with wild-type transthyretin-related amyloidosis (n = 10), carriers of the Danish familial transthyretin amyloidosis mutation with cardiac involvement (n = 5), and patients with amyloid light chain amyloidosis with cardiac involvement (n = 12). All subjects underwent comprehensive echocardiographic evaluation during rest and during symptom-limited, semisupine exercise testing. Furthermore, CFVR was assessed using Doppler echocardiography.

  Results
  Patients with CA had significantly lower CFVR (1.7 ± 0.6 vs 3.9 ± 0.8, P < .0001), MWE (1.9 ± 1.0 vs 3.0 ± 0.7, P < .0001), and LVGLS magnitude (11% [10%–14%] vs 20% [18%–21%], P < .0001) than control subjects. Patients with CA showed severely reduced deformation and efficiency reserve compared with control subjects (ΔLVGLS 0.9 ± 2.8% vs 5.6 ± 2.3%, P < .0001; ΔMWE 2.5 ± 2.8 vs 8.8 ± 2.6, P < .0001). In patients with CA, a strong relation was seen between physical capacity by the metabolic equivalent of tasks test and CFVR (r = 0.55, P < .01), peak exercise LVGLS (r = 0.64, P < .0001), and peak exercise MWE (r = 0.60, P < .01).

  Conclusions
  Patients with CA had a profound lack of CFVR and longitudinal myocardial deformation reserve compared with healthy control subjects. Both parameters were significantly associated with exercise capacity and may prove useful for evaluating cardiac performance in patients with CA.

  Download publication

  Close
• Diagnosis of myocardial viability by exercise echocardiography

  ×

  Diagnosis of myocardial viability by exercise echocardiography

  Author(s)

  Hirano Y, Yamamoto T, Uehara H, Ozasa Y, Yamada S, Ikawa H, Ishikawa K.

  Date

  1999-09-01

  Source

  Journal of Cardiology

  This study determined whether the diagnosis of myocardial viability could be established on the basis of the contractile reserve during low level exercise with an ergometer using echocardiography. The study involved 22 patients with transmural old myocardial infarction who underwent exercise echocardiography, followed by coronary intervention after a mean 4 days. Exercise echocardiography was started from 50 W and stepped up by 25 W every 3 min up to a maximum of 150 W. Low level exercise was administered for 1 to 2 min at 50 W. A 16-segment model was used for the left ventricular wall motion, which was evaluated by five-grade scoring, ranging from normokinesis to dyskinesis. If patients showed improvement by one point or more in the score for segments of dyskinesis, akinesis, or severe hypokinesis on the exercise echocardiography, they were considered to have positive viability. The golden standard for the diagnosis of myocardial viability was that wall motion abnormalities before exercise echocardiography should be improved by one point or more after coronary intervention. Before exercise echocardiography, there were 152 segments showing wall motion abnormalities assessed as severe hypokinesis or more. After coronary intervention, improvement of the wall motion by one grade or more was found in 2 of the 18 segments (11%) for dyskinesis, in 38 of the 96 segments (40%) for akinesis, and in 22 of the 38 segments (58%) for severe hypokinesis; improvement for the segments of severe hypokinesis was significantly better than those for dyskinesis and akinesis. Out of 19 segments with akinesis before exercise echocardiography in which wall motion was improved during low level exercise, 16 segments (84%) showed improvement in wall motion after coronary intervention. Out of 77 segments with akinesis before exercise echocardiography in which no change or worsening was seen during low level exercise, 22 segments (29%) showed improved wall motion after coronary intervention. There were 38 segments with severe hypokinesis before exercise echocardiography; out of 12 segments in which wall motion was improved during low level exercise, 7 segments (58%) showed improved wall motion after coronary intervention. Out of 26 segments with severe hypokinesis before exercise echocardiography in which no change or worsening was seen during low level exercise, 11 segments (42%) showed improved wall motion after coronary intervention. Wall motion was improved after coronary intervention in 20 of 25 segments (80%) that showed the biphasic response, in 4 of 7 segments (57%) that showed improvement, in 14 of 43 segments (33%) that showed worsening, in 24 of 77 segments (31%) for no change; the biphasic response showed a significantly higher improvement compared to worsening or no change. If segments in which wall motion was improved during low level exercise are regarded as positive viability segments, occurrences of the sensitivity, specificity and diagnostic accuracy of myocardial viability were 50%, 84%, and 71%, respectively.

  Download publication

  Close
