Lode Cardiac Rehab Manager

Turn-key Solution for Cardiac Rehabilitation
Lode offers a turn-key solution for cardiac rehabilitation. The complete solution consists of our intuitive and user-friendly LCRM software, a very compact wearable ECG streamer and is completed with our reliable Lode rehab ergometers.
The LCRM software (#950902) is unique and control the Lode rehab devices. It helps the test operator to prepare cardiac rehabilitation sessions by the possibility to predefine protocols and test groups. The software also documents all relevant data (e.g. ECG, BPM, SpO2, Speed, Inclination, RPM, Load, etc) for later analysis and provides individual reports and continuous ECG control. The test operator can rely on the quality of the software and thus focus on the patients. The extensive patient database can work as a stand-alone database or linked to a SQL server. Of course HL7 connection to the Hospital Information System (HIS) is possible.
The compact 2-channel ECG streamer (#950920) is wearable and wireless. This makes it possible for the test subject to move around the ergometer and perform all kind of exercises while the ECG data are still monitored. The batteries of multiple ECG streamers can be charged using a USB cord or simultaneously in a docking station.
Each Cardiac Rehabilitation Solution is custom made, based on the requirements of the user. You can use part number #950902 for ordering the LCRM software for a setting with 2 stress test devices. For each additional device, you can order an additional license (#950906). For a complete setup, please check the accessories and related products or contact your local Lode distributor.

Interconnectivity between Lode products [sg_popup id=”4732″ event=”click”]Read More[/sg_popup]

Analyzing the LCRM training data [sg_popup id=”5912″ event=”click”]Read More[/sg_popup]

Documentation [sg_popup id=”5916″ event=”click”]Read More[/sg_popup]
Complete setup turn key delivered [sg_popup id=”5917″ event=”click”]Read More[/sg_popup]

SKU: 1-Rehab Category: Rehabilitation

Overview

High standardsLode is a socially and environmentally responsible company. All Lode products are RoHS/WEE compliant and Lode is ISO 9001:2015, ISO and 13485:2016 certified. All medical products comply to MDD 93/42/EEC, incl. IEC 60601-1.

Complete setupThe modular structure of the software combined with the accurate and reliable Lode ergometers offers a complete and modern ergometry setting.

Everything in controlEasy set up of Subject data

Create protocols quickly and efficiently

Overview of progress during test

Multifunctional software for all Lode ergometersThe software can be used for all Lode ergometers and treadmills, including their options like bloodpressure, heart rate, SpO2 etc.

Load as well as bloodpressure triggers can be set remotely.

Easy to install– Simple step by step installer, Easy setup of ergometers and subjects

Features

Turn Key Delivery

The complete setup is delivered turn key, so that you can start using it immediately.

Patient Database

An extensive patient database is available, which can work as a stand alone database or linked to a SQL server. HL7 connection to the Hospital Information System (HIS) is possible.

Data dashboard available

Various ergometry data is made visible, enabling the operator to simultaneously visualize ergometric parameters during the test and to control or quickly intervene when necessary.

Monitor during the test

The visualisations on the monitor can be selected by the operator to define a clear and usefull visual overview during the exercise test. The lay-outs for different purposes can be saved by the operator

Customisable view

The operator can define which data is displayed on the screen. Data not visualized during the test is recorded and can be analyzed at any time.

Add remarks

Remarks can be added and modified before, after and
during the test

Multiple analysis modes

Easy access to Analysis menu. Creating individual comparisons with an overview of the performed tests.

Borg RPE scale integrated

Ratings of Perceived Exertion: an aid to help estimate the amount of exertion, the load and fatigue on a scale of 6 to 20.

Specifications

Accuracy

60 Hertz Filter
60 Herz ECG Filter

50 Hertz Filter
50 Hertz ECG Filter

Two channel ECG monitoring
ECG monitoring with 4 leads, two channel

Comfort

Alarm Heart Rate
Alarm Heart Rate

Alarm Blood Pressure
Alarm Blood Pressure

Audio Alarm
Audio Alarm

Remote Battery Indication
Remote Battery Indication

Versatile database connection
Versatile database connection

User Interface

Customized Screenviews
Customized Screenviews

Customized Reports
Customized Reports

Personalized Color Settings
Personalized Color Settings

Software available in English
Software available in English

Software available in German
Software available in German

Software available in Dutch
Software available in Dutch

Software available in French
Software available in French

Software available in Russian
Software available in Russian

Software available in Polish
Software available in Polish

Software available in Japanese
Software available in Japanese

Connectivity

RS232 connection to Lode ergometers
RS232 connection to Lode ergometers

USB connection to Lode treadmills
USB connection to Lode treadmills

Bluetooth available
connectivity through Bluetooth available

Max. wireless slots per monitor 8 the maximum number of test subject that can be connected

Minimum System Requirements

Intel Core based processor 2.4 GHz processor family

Monitor 1920 x 1080 pixels Resolution

Internal RAM 4000 MB minimum PC internal memory

Minimum Free Hard Disk space 20 GB software and storage size requirement

CD Rom drive required
installation medium input

Number of free USB ports 1 for connection purposes

Mouse
for input

Keyboard

Compatability

HL7 compatible
HL7 compatible

Compatible with MS SQL Server
Can be connected with MS SQL Server

Database SQL Compact Database used

Database limit 4 GB Database limit when used as local database

Microsoft Windows 10
compatible with Microsoft Windows 10

Microsoft Windows 8
compatible with Microsoft Windows 8

Microsoft Windows 7
compatible with Microsoft Windows 7

Included parts

PC included
the software is preinstalled on a PC that is included

PC software included
software needed for operation included

Windows 7 installed
operating system preinstalled on PC

Keyboard and mouse included
Input devices are included with the PC

LCD screen included
large display for monitoring patients

All cables included
cables for installing the complete setup are included

*Specifications are subject to change without notice.

Accessories

[wcsp_cross_sell orderby=”rand” order=”ASC” product_num=”5″ display_columns=”3″ title=”” product_id=”5909″]

Science

Effects of cardiac rehabilitation and exercise training programs on depression in patients after major coronary events

Effects of cardiac rehabilitation and exercise training programs on depression in patients after major coronary events

Author(s)

Richard V. Milani, Carl J.Lavie MD, Mark M. Cassidy MD

Date

1996-10-01

Source

American Heart Journal, Volume 132, Issue 4, October 1996, pages 726 – 732

To evaluate the effect of cardiac rehabilitation and exercise training on depression after major cardiac events, we studied 338 consecutive patients in whom a major cardiac event had occurred 4 to 6 weeks previously and who were participating in phase II cardiac rehabilitation consisting of 36 sessions over a 3-month period. Depressive symptoms and other behavioral characteristics and quality-of-life parameters were analyzed by validated questionnaire. Depression was prevalent in patients with coronary heart disease, occurring in 20% of the patients evaluated. At baseline, depressed patients had lower exercise capacity, reduced high-density lipoprotein cholesterol level, and higher triglyceride levels; had lower scores for mental health, energy or fatigue, general health, pain, overall function, well-being, and total quality of life; and had greater scores for somatization, anxiety, and hostility than those of nondepressed patients. After cardiac rehabilitation, depressed patients had marked improvements in depression scores and other behavioral parameters (anxiety, somatization, and hostility) and quality of life. Depressed patients also showed improved exercise capacity, percentage of body fat, and levels of triglycerides and high-density lipoprotein cholesterol. Depressed patients exhibited statistically greater improvements in certain behavioral and quality-of-life parameters than did nondepressed patients. Two thirds of the patients who were initially depressed resolved their symptoms by study completion. In conclusion, depression is reduced in patients with symptomatic coronary heart disease patients enrolled in cardiac rehabilitation. Greater emphasis is needed to ensure that depressed patients are referred to and attend formal cardiac rehabilitation programs after major cardiac events.

Download publication
Exercise with cardiac patients

Exercise with cardiac patients

Author(s)

Project Group “Sport and Exercise Therapy in Cardiology”

Date

2012-07-01

Source

DVGS e.V. (German Association for Health-Related Fitness and Sport Therapy)

Physical activities are a natural necessity and — just as targeted training — result in lower cardiovascular and overall mortality of cardiac patients, while also improving these patients’ prognosis, quality of life, and physical performance. They can therefore be considered an independent therapeutic method that is equal to therapy approaches based on medication, intervention, and surgery and can supplement them in a meaningful way. Sports therapy and physical education measures help patients acquire individual resources and abilities and have the potential to contribute to a change in exercise-related lifestyle. According to current insights, a beneﬁcial exercise and training program for cardiac patients should include endurance and strength training. The following training recommendations for cardiac patients are intended to allow for therapeutically supported, dosed, controlled, and hence, successful management of training measures for people with cardiovascular diseases.

Download publication

Support

Q - Is it possible to control the Lode ergometers and treadmills with external equipment

Yes, you can find interface sheets for most common devices on the website at the "service" tab of this website. If your device is not present you can ask us to support you. In most cases we can quickly provide you with a solution.

Q - Can the Valiant be controlled by LCRM?

Yes the Valiant Treadmill can be controlled by LCRM. The treadmill is supplied with a RS232 port and can be controlled by a seperate com port.

Q - Is the SpO2 option compatible with LCRM?

Yes the SpO2 results are visible during the rehab session.

Q - How do I switch off the ECG module.

For turning off the legacy ECG module (950910/950913) - Hold the power button for a few seconds until the LED turns an amber color. Continue holding the button until the LED blinks and goes amber again. On the second amber flash, release the power button. This will power down the device.

Q - Can I loop Lode rehab products easily?

Yes! It is very easy to create a comfortable rehab setting with Lode rehab products by looping the ergometers:

The first Lode rehab ergometer can be connected to the PC with LCRM with a Lode proprietary network to PC cable (#930930).
The second product up till the last product can be connected to the previous one, a bus network configuration.

The last product always needs a termination plug to avoid interference and loss of data. All Lode rehab products come standard with such a termination plug.

Benefits
- Flawless data connection
- High bandwidth
- No interference of COM ports
- Looping
- Full access of all data in the product to LCRM

Service

Part number 950902

Reviews
